What is the reason for the uneven winding of the rolling machine

The coiling machine is used to roll the fabric after the process of scouring, bleaching, printing and dyeing, etc., which is convenient for centralized material placement. The motor drives the expansion and contraction reel to rotate, and drives the continuous material tape to be wound into a material roll.

photobank

The reasons for the uneven winding of the rolling machine are:

1. The center line of the rolling machine and the fabric is not on the same line during the rotation process, resulting in uneven winding;

Solution: Check whether the center line of the winder mechanism is consistent with the fabric edge, and adjust it immediately if it is inconsistent.

2. The material stop limit device of the winding mechanism has not been reliably limited, resulting in uneven winding;

Treatment method: Adjust the material stop device, usually the position of the A-type iron, so that it can effectively limit the winding material.

3. The material head is not adjusted properly when leading the material, and the winding starts, resulting in uneven winding;

Treatment method: When the winder is in use, it should be manually wound 5-6 times in the early stage to ensure that the material head is wound neatly.

4. The thickness of the winding material tape is uneven, one side is thick and the other is thin, and the winding speed is different;

Treatment method: You can properly adjust the winding speed to ensure that the winding is tightened.

5. Incomplete collection caused by insufficient tension.

It is necessary to install a tensioning device, and use the tensioner to continuously maintain the tension on the winder, so as to ensure that the materials with uneven thickness can be neatly collected.
