The existing cloth winding machine will carry out the alignment when rolling the cloth. The principle of the alignment is to detect whether the alignment is neat when the cloth is rolled by the red line detector. align. However, this crimping method needs to drive the entire cloth rolling mechanism, including the cloth rolling drum, the motor connected to the cloth rolling drum, and the rolled cloth, etc., and a corresponding slideway needs to be set, which not only makes the structure of the entire cloth rolling machine complicated, The energy consumption is high, and the vibration generated by its overall shaking is also likely to cause mechanical failure.
Technical realization elements:
In order to solve the above problems, REHOW provides a cloth rolling machine. The utility model has simple structure, convenient and quick adjustment, greatly saves the structure of the existing cloth rolling machine, and the cloth rolling is smooth.
In order to achieve the above technical effects, the technical solution of rehow to produce a new type of cloth winding machine is:
It includes a cloth roll and a guide roller. Along the direction of the cloth, an adjustment roller is installed between the cloth roll and the guide roller; one end of the adjustment roller is hinged and fixed, and the other end is connected with a stretching device; For the detection device, the detection device controls the operation of the stretching device through the controller.
As a further improvement, a distribution roller is installed between the adjustment roller and the guide roller. The surface of the distribution roller described by Suzhou rehow fabric inspection and rolling machine manufacturer protrudes from the middle to both sides with left external threads and right external threads respectively. Thread left external thread and right external thread have the opposite helical direction.
REHOW provides cloth winding machine automation system to the whole world, including software system, industrial computer, printer, in order to guide customers to use our system, help them improve efficiency and reduce labor cost, we have prepared instructional videos in our youtube.
rehow provides various types of automatic textile machinery such as: raising machine, cloth inspection machine, packaging machine, coiling machine, slitting machine, cloth coder, folding and rolling machine, cross cutting machine, ribbon weaving machine, loom and so on. If you are interested in us, please contact us now!
